Solar 12V 100Ah 200Ah LiFePO4 Lithium Ion Batter
Solar 12V 100Ah 200Ah LiFePO4 Lithium Ion Batter
1
Quantity
Product Paramenters
| S/N | Project | General Parameter |
| 1 | Number of series | 4S |
| 2 | Rated voltage | 12V |
| 3 | End of discharge voltage | 48V |
| 4 | Charging voltage | 14.2-14.6V |
| 5 | Charge Mode | 0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV) |
| 6 | Cycle Life | >2000 cycles @0.5C 100%DOD |
| 7 | Self-discharge rate | ≤3%/month |
| 8 | range of working temperature （≤95%R.H.） | 0～50℃ charge -20～60℃ discharge |
| 9 | Storage temperature range（≤95%R.H.） | 0～45℃ |
| 10 | Max Continuous Discharge Current | 100A (Can be customized) |
| 11 | Max. Charge Current | 100A |
| 12 | Protective function | Overcharge, over discharge, short circuit, overload, over temperature, etc. |
| 13 | certificate | MSDS,ISO9001,CE,UN38.3 |
