Voltage ( V )

Capacity ( Ah )

BMS Current ( MaxA )

Charger ( A )

Dimension ( mm )

Color

36

15-35

20

2-4

430*160*90

White or Silver

48

10-31.5

30

2-3

430*160*90

White or Silver

1. Technical Data

Model No.

UPP-S045

Rated Voltage

48V

Rated Capacity

20Ah

Cells

18650 G25

BMS

30A

Combination

5P 13S

Discharge Cut-Off Voltage

36.4V

Charge Cut-Off Voltage

54.6V

Standard Charge Current

2A

Max Charge Current

3A

Cycle Life

 80% power after 800 cycles

Application

48V 400W - 800W Electric Bicycle and Scooter

2. Basic Data

Size

430*160*85mm

Battery Material

Li(NiCoMn)O2 18650

Case Material

 High Hardness Plastic

Warranty

12 months and longer, offer local repair in Germany

 Charging Temprature

0 ~ 45 Celsius

Discharging Temprature

-20 ~ 60 Celsius

3. Packing List

Battery * 1PC

54.6V3A Charger with UK plug * 1PC
